When making the connection with aluminum wire, make sure that you are using connectors identified CO/ALR. Pass the wires from the wall through the hole at the base of the mounting base and connect them using the solderless connectors supplied.Align and secure the mounting base to the connection box using the two screws supplied.Then, remove the mounting base at the back of the thermostat by tilting it downward, then towards you.

Using a screwdriver, loosen the screw retaining the mounting base of the thermostat (do not completely remove the screw).Ensure that the air vents of the Ki thermostat are clean and clear of any obstruction.If an existing thermostat is being replaced, remove the previous thermostat.Cut off the power supply on lead wires at the electrical panel in order to avoid any risk of electric shock.behind a door) or with frequent air drafts (e.g. exposed directly to the light or heat of the sun, a lamp, a fireplace or any other heat source.close to a window, on an external wall, or close to a door leading outside.

Dirt 5 controller settings install#

The thermostat must be mounted to a connection box on a wall facing the heating unit, at around 1.5 m (5 feet) above the floor level, on a section of the wall exempt from pipes or air ducts.ĭo not install the thermostat in a location where temperature measurements could be altered.

two (2) solderless connectors suitable for copper wires INSTALLATION.

one (1) wall mounting plate located at the back of the thermostat.

However, installing it in insulated walls is allowed. Do not install a thermostat in a wet place. Do NOT use fluid to clean thermostat air vent. You must regularly clean dirt accumulations on the thermostat. Protect the heating system with the appropriate circuit breaker or fuse.

All electric connections must be made by a qualified electrician, according to the electric and building codes effective in your region.ĭo NOT connect this product to a supply source other than 120 VAC or 240 VAC, and do not exceed the load limits specified. Moreover, the following instructions must be adhered to in order to avoid bodily harm or property damages, serious injuries, and potentially fatal electric shocks. If these instructions are not followed, the warranty will be considered null and void and the manufacturer deems no further responsibility for this product. Before installing and operating this product, the owner and/or installer must read, understand and follow these instructions and keep them handy for future reference.
